MOUNT CLEMENS SUBDIVISION FOOTNOTES
1.1 CLEARANCES
WEST DETROIT - Eastward trains may leave without clearance. Train movements on the Mount Clemens Subdivision entering the Holly Subdivision at Milwaukee Jct. are not required to obtain clearance at Milwaukee Jct. but must obtain permission to enter the Holly Subdivision from the Train Dispatcher.
MILWAUKEE JCT. - All westward trains to the Shore Line Subdivision must obtain clearance.
FOREST LAWN - All eastward trains must obtain a clearance.
TAPPAN - Westward trains leaving Tunnel Yard must obtain a clearance at Tappan.
1.2 TRAIN REGISTER MODIFICATIONS MILWAUKEE JCT. - *Register station for trains originating and terminating. Tunnel Yard - *Standard Clock and Bulletins only.
1.3 ABS AND CTC SPECIAL FEATURES BLOCK AND INTERLOCKING SIGNALS - The following Dwarf Signals are used in lieu of High Mast Signals to display GTOR Rules 281, 285 and 291, respectively.
Mileage 1.8 Signal 18, Eastward.
Mileage 1.8, Signal 17, Westward.
2.1 Security locks now replace GTW switch locks on Main Track switch stands between mileage 11.8 and mileage 50.0.
2..2 Mileage 0.7 hand rails on bridge, have been removed.
2.3 MILWAUKEE JCT. - Movements receiving STOP signal indication at signals 44 or 45 located at Mileage 4.4 will be governed by GTOR Rule 509.
All movements must obtain permission from Train Dispatcher Pontiac Yard to enter on and must report clear of the Main Track between mileage 0.0 and mileage 4.6, High Line 3 track, and Tunnel Track.
GTOR Rule 514 will govern movements entering between signals in this territory after permission has been obtained from Train Dispatcher Pontiac Yard.
Conrail Operators Milwaukee Jct., Beaubien Street and West Detroit must receive permission from Train Dispatcher Pontiac Yard to authorize movement to pass a stop signal or before lining movements into the territory between Milwaukee Jct. and West Detroit.
Permission to enter or report clear may be relayed through the GT Operator Milwaukee Jct.
Mileage 5.7, East Yard - the new connection between the Conrail Main Track and the GTW Long Interchange Track located just west of Conant Avenue, is placed in service.
The switch at the west end of the connection on the Conrail Main Track is a power switch within the Conrail, Milwaukee Junction Interlocking limits, controlled by the Conrail Operator, Milwaukee Junction.
The switch at the east end of the connection on the Long Interchange Track is a spring switch with the normal position lined for the Long Interchange Track. A dwarf signal has been installed at the switch to protect facing point movements. Restricting signal indication denotes switch properly lined, movement may proceed at restricted speed. Movements receiving stop signal will be governed by Special Instruction 1.4.
2.4 MOUNT CLEMENS - All movements on Cooper's lead over Church Street, mileage 21.7 must be protected by a member of the crew.
Employees must not pass the restricted clearance sign located 50 feet north end of Ford Motor Company Vinyl Plant, Track No. 1.
Railroad gates at Selfridge Field are equipped with switch lock and are to be closed and locked when not in use. Enginemen and trainmen, when entering Selfridge Field, can expect to find this gate in a closed position and locked.
2.5 TAPPAN - Trains operating east of Tappan will be governed by Flint Subdivision Footnotes.
2.6 JOINT MAIN TRACK
WEST DETROIT to BEAUBIEN ST. - Main Track joint with N&W. GTW timetable and rules govern.
3.1 Railway crossing at grade.
CR .... Mileage 3.8. . Mechanical.
3.2 Railway crossing at grade.
Holly Sub .... Mileage 4.6 .... Mechanical.
3.3 Railway crossing at grade.
CR .... Mileage 7.0 .... Mechanical.
3.4 Railway crossing at grade.
C&O .... Mileage 55.6 .... Mechanical.
3.5 Junction.
Flint Sub.. . . . Mileage 55.6 .... Mechanical.
4.1 Cars exceeding 315,000 lbs. gross must be covered by handling instructions.
5.1 Mileage 11.3, Double Track Switch - Normal position lined for westward movement to Westward Track. Automatic Block Signal No. 113, located 10 feet east of switch, governs facing point movement.
Mileage 4.7 Mileage 7.1 Mileage 4.8 Mileage 7.9 Mileage 5.6 Mileage 9.0 Mileage 6.8
7.1 Switch Key or Pull Button Control Instructions: Special Instruction 9.2 applies.
8.1 Mileage 25.6.
Special Instruction 8.1 applies for above location.
9.1 Mileage 15 ' 9 Great Lakes Paper Co., 460 feet in length, switch points face E. Station Number 508.
9.2 Mileage 21.5, Jamestown China Co., 1368 feet in length, switch points face E. Removable conveyor and a removable runway for HI-LO located 780 feet North of switch. Station Number 507.
9.3 Mileage 2.4, Ford Vinyl Plant, cars must not be left on lead foul of the gate. All tracks must be switched with air coupled and in service. Station Number 507.
9.4 Mileage 23.0, Ford Paint Plant, track 4 must be switched with air coupled and in service. Station Number 506.
9.5 Mileage 23.0, Selfridge Field Spur, 30,000 feet in length, switch points face W. (Note - Engines must not exceed 8 miles per hour between Elizabeth St., and Gratiot Ave., Selfridge Field Spur, Mount Clemens.) Station Number 506.
9.6 Mileage 24.0, Petitpren Inc., 933 feet in length, switch points face E. Station Number 508.
9.7 Mileage 24.2, Reynolds Aluminum Recycling, 618 feet in length, switch points face E. Station Number 507.
9.8 Mileage 24.3, Vic Wertz Dist., 741 feet in length, switch points face E. Station Number 507.
9.9 Mileage 25.2, Erb Lumber Co., 1400 feet in length, switch points face W. Station Number 508.
9.10 Mileage 27.2, Chesterfield Industrial Park Spur, switch points face W. Station Number 505.
9.11 Mileage 44.9, Columbus, 350 feet in length, switch points face E. Station Number 502.
9.12 Mileage 52.0, Port Huron Truss Go., 515 feet in length, switch points face W. Station Number 801.
9.13 Mileage 52.3, Carter Lumber Co., 530 feet in length, switch points face E. Station Number 801.
